ACL Mazda B6/BP/BP-T 1.6/1.8L Standard Size High Performance Rod Bearing Set
Images are supplied by the manufacturer and may be generic. While all efforts are made to provide accurate pictures, there may be differences in the actual product, such as colour, quantity, version, or included items. Please carefully review the description and specifications for details on inclusions or any variations. Some items may be sold individually or in sets, and images may occasionally depict additional products or quantities not included in your purchase. For assistance or clarification, please contact customer support.
Rod Bearings, Race Series, Tri-Metal, Mazda, Set of 4
ACL Performance offers Race Series rod bearing sets for a wide range of vehicles. These high performance tri-metal engine bearings are designed to withstand higher RPM conditions. They feature a high-strength overlay plate with reduced thickness for improved fatigue properties. Select the crankshaft undersize and quantity recommended for your year/make and engine application. Additional details: * Hardened steel backs on all rod bearings to improve the support of the bearing lining and assist with bearing retention in the housing. * Increased crush for improved bearing retention * Elimination of flash plating on the back of the bearings to improve heat transfer through the bearings and to maximize the grip between the bearings and its housing * Increased eccentricity to compensate for bore distortion at high RPM and to assist in the formation of hydrodynamic oil films * 3/4 in. grooved main bearings to optimize bearing load carrying surface area and oil flow to the conrod bearings * Tight consistent wall tolerances to help you maintain consistent clearances * Enlarged ID chamfers on bearing edges (where required) to accommodate large fillet radius on performance crankshafts
UPC | 9315726318584 |
Brand | ACL Race Series Performance Engine Bearings |
Quantity | Sold as a set of 4. |
Part Type | Rod Bearings |
Product Line | ACL Performance Race Series Rod Bearing Sets |
Bearing Usage | Performance |
Dowel Pin Hole | No |
Narrow Bearing | No |
Bearing Material | Tri-metal copper-lead alloy |
Manufacturer's Part Number | 4B8351H-STD |
Engine Crankshaft Undersize (mm) | Stock |
Engine Crankshaft Undersize (in.) | Stock |
ACL Mazda B6/BP/BP-T 1.6/1.8L Standard Size High Performance Rod Bearing Set | ||||
---|---|---|---|---|
Year Range | Make | Model | Submodels | Region |
2001-2005 | Kia | Rio | Base, Cinco | US |
1994-1997 | Kia | Sephia | GS, LS, RS | US |
1986-1994 | Mazda | 323 | Base, DX, LX, SE, GTX, GT | US |
1992-1995 | Mazda | MX-3 | Base | US |
1990-1997 | Mazda | Miata | Base, SE, LE, M Edition, STO | US |
1999-2005 | Mazda | Miata | 10th Anniversary, Base, LS, SE, Shinsen, Mazdaspeed | US |
1990-2001 | Mazda | Protege | LX, ES, DX | US |
1991-1994 | Mercury | Capri | Base, XR2 | US |
Please note that this information serves as a fitment guide only. For specific fitment questions or clarifications, please contact us, as manufacturers may introduce variations and modifications during model year or regional revisions. While we strive to provide accurate data, fitment details may vary by region; therefore, compatibility outside the listed region and submodel variant cannot be guaranteed.
Application Data | |
---|---|
Make | MAZDA |
Beginning Year | 1981 |
Ending Year | 1985 |
Engine Type | L4 |
Engine Family | Mazda 4-cylinder |
Engine Size | 1.5L/1490cc |
Make | MAZDA |
Beginning Year | 1986 |
Ending Year | 1995 |
Engine Type | L4 |
Engine Family | Mazda 4-cylinder |
Engine Size | 1.6L/1597cc |
Make | MAZDA |
Beginning Year | 1988 |
Ending Year | 1988 |
Engine Type | L4 |
Engine Family | Mazda 4-cylinder |
Engine Size | 1.6L/1597cc |
