SOHC - Xtreme Energy: Hot street cam, needs lower gear ratio. 2000+ stall. Intake, exhaust and custom tuning required. Noticeable idle.
COMP Cams Xtreme Energy 270AH-13 Camshaft Set for 4.6L and 5.4L SOHC Modular 2 Valve Ford with 1999-up Performance Improvement Heads
Engine Camshaft
COMP Cams Xtreme Energy modular 2-valve camshafts are specifically created for high-demanding, overhead-camshaft engine configurations. From stock replacements to ultimate performance, there is an Xtreme Energy cam to meet your performance goals.
Brand | COMP Cams |
Manufacturer's Part Number | 102600 |
Part Type | Camshafts |
Product Line | COMP Cams Xtreme Energy Modular 2-Valve Camshafts |
Summit Racing Part Number | CCA-102600 |
UPC | 036584072737 |
Cam Style | SOHC |
Camshaft Use | Street/Strip |
Camshaft Manufacturers Description | Hot street cam, needs 3.55+ gears with 2000+ stall. Intake, exhaust, computer and 26113 springs recommended. Noticeable idle. |
Basic Operating RPM Range | 1,800-5,800 |
Intake Duration at 050 inch Lift | 234 |
Exhaust Duration at 050 inch Lift | 238 |
Duration at 050 inch Lift | 234 int./238 exh. |
Advertised Intake Duration | 270 |
Advertised Exhaust Duration | 274 |
Advertised Duration | 270 int./274 exh. |
Intake Valve Lift with Factory Rocker Arm Ratio | 0.550 in. |
Exhaust Valve Lift with Factory Rocker Arm Ratio | 0.550 in. |
Valve Lift with Factory Rocker Arm Ratio | 0.550 int./0.550 exh. |
Lobe Separation (degrees) | 113 |
Remanufactured | No |
Computer-Controlled Compatible | Yes |
Grind Number | XE270AH |
Valve Springs Required | Yes |
Quantity | Sold as a pair. |
Notes | Fits 2V SOHC engines only. For 1999 and later performance improvements heads. Can also be used in 1998 and earlier heads with retainer to guide clearance modifications and Comp Cams valve springs. |
Compatibility & Application Information | |
---|---|
Make | FORD |
Beginning Year | 1999 |
Ending Year | 2014 |
Engine Type | V8 |
Engine Family | Ford modular V8 |
Engine Size | 4.6L/281 |
Application Notes | Fits 2-Valve Power Improver Heads only. |
Make | FORD |
Beginning Year | 1999 |
Ending Year | 2016 |
Engine Type | V8 |
Engine Family | Ford modular V8 |
Engine Size | 5.4L/330 |
Application Notes | Fits 2-Valve Power Improver Heads only. |
Make | FORD |
Model | CROWN VICTORIA |
Submodel | BASE |
Beginning Year | 1992 |
Ending Year | 2008 |
Engine Type | V8 |
Liter | 4.6 |
CID | 281 |
Engine Family | Ford modular V8 |
Engine Size | 4.6L/281 |
Application Notes | Aspiration: Naturally Aspirated, Cylinder Head Type: SOHC, Engine Manufacturer: Ford, Engine Version: N/R, Valves Per Engine: 16 |
Engine VIN Code | W |
Make | FORD |
Model | CROWN VICTORIA |
Submodel | BASE |
Beginning Year | 1996 |
Ending Year | 1996 |
Engine Type | V8 |
Liter | 4.6 |
CID | 281 |
Engine Family | Ford modular V8 |
Engine Size | 4.6L/281 |
Application Notes | Aspiration: Naturally Aspirated, Cylinder Head Type: SOHC, Engine Manufacturer: Ford, Engine Version: Triton, Valves Per Engine: 16 |
Engine VIN Code | 6 |
Make | FORD |
Model | CROWN VICTORIA |
Submodel | BASE |
Beginning Year | 1996 |
Ending Year | 2005 |
Engine Type | V8 |
Liter | 4.6 |
CID | 281 |
Engine Family | Ford modular V8 |
Engine Size | 4.6L/281 |
Application Notes | Aspiration: Naturally Aspirated, Cylinder Head Type: SOHC, Engine Manufacturer: Ford, Engine Version: N/R, Valves Per Engine: 16 |
Engine VIN Code | 9 |
COMP Cams Camshaft Set F4.6S XE270AH-13 | ||||
---|---|---|---|---|
Year | Make | Model | Submodel | Region |
1991 | Lincoln | Town Car | Base | US |
1991 | Lincoln | Town Car | Signature | US |
1991 | Lincoln | Town Car | Cartier | US |
1991 | Lincoln | Town Car | Cypress | US |
1991 | Lincoln | Town Car | Executive | US |
1991 | Lincoln | Town Car | Touring Edition | US |
1992 | Ford | Crown Victoria | Touring Sedan | US |
1992 | Ford | Crown Victoria | LX | US |
1992 | Ford | Crown Victoria | S | US |
1992 | Lincoln | Town Car | Cypress | US |
1992 | Lincoln | Town Car | Touring Edition | US |
1992 | Lincoln | Town Car | Base | US |
1992 | Lincoln | Town Car | Executive | US |
1992 | Mercury | Grand Marquis | LS | US |
1992 | Ford | Crown Victoria | Base | US |
1992 | Lincoln | Town Car | Signature | US |
1992 | Lincoln | Town Car | Cartier | US |
1992 | Mercury | Grand Marquis | GS | US |
1993 | Ford | Crown Victoria | Police Interceptor | US |
1993 | Lincoln | Town Car | Touring Edition | US |
1993 | Ford | Crown Victoria | LX | US |
1993 | Lincoln | Town Car | Cartier | US |
1993 | Lincoln | Town Car | Base | US |
1993 | Mercury | Grand Marquis | LS | US |
1993 | Lincoln | Town Car | Signature | US |
1993 | Lincoln | Town Car | Executive | US |
1993 | Mercury | Grand Marquis | GS | US |
1993 | Ford | Crown Victoria | Base | US |
1993 | Ford | Crown Victoria | S | US |
1993 | Lincoln | Town Car | Jack Nicklaus | US |
1993 | Lincoln | Town Car | Cypress | US |
1994 | Mercury | Cougar | XR-7 | US |
1994 | Ford | Crown Victoria | LX | US |
1994 | Ford | Crown Victoria | S | US |
1994 | Lincoln | Town Car | Cartier | US |
1994 | Lincoln | Town Car | Touring Edition | US |
1994 | Ford | Thunderbird | LX | US |
1994 | Mercury | Grand Marquis | LS | US |
1994 | Ford | Crown Victoria | Base | US |
1994 | Ford | Crown Victoria | Police Interceptor | US |
1994 | Lincoln | Town Car | Executive | US |
1994 | Lincoln | Town Car | Signature | US |
1994 | Lincoln | Town Car | Cypress | US |
1994 | Lincoln | Town Car | Tournament Edition | US |
1994 | Lincoln | Town Car | Base | US |
1994 | Mercury | Grand Marquis | GS | US |
1995 | Lincoln | Town Car | Base | US |
1995 | Mercury | Grand Marquis | LS | US |
1995 | Ford | Crown Victoria | Police Interceptor | US |
1995 | Lincoln | Town Car | Signature | US |
Note: Over 50 fitments returned for this product, this table is trimmed to only display the first 50. |
