Mahle PowerPak piston and ring kits include forged pistons, low-drag rings, steel pins, and wire locks—all in one race-proven package. The pistons are hand-deburred and then coated with dry phosphate to protect against ring micro-welding and pin galling during initial startup. For additional performance, Mahle added its proprietary Grafal anti-friction coating to the piston skirts. These replacement packages are available in a wide variety of size options for fitment with specific engines and pistons.
Brand | Mahle |
Stroke | 3.661 in. |
Gapless | Yes |
File Fit | Yes |
Quantity | Sold as a kit. |
Bore (mm) | 94.005mm |
Part Type | Pistons |
Bore (in.) | 3.701 in. |
Rod Length | 5.933 in. |
Piston Style | Dome, with two valve reliefs |
Product Line | Mahle PowerPak Piston and Ring Kits |
Piston Material | Forged aluminum |
Wrist Pin Style | Press-fit or floating |
Oil Ring Tension | Standard |
Oil Ring Material | Stainless steel |
Top Ring Material | Ductile iron |
Oil Ring Thickness | 2.0mm |
Pin Diameter (in.) | 0.827 in. |
Top Ring Thickness | 1.0mm |
Wrist Pin Included | Yes |
Second Ring Material | Cast iron |
Piston Ring Thickness | 1.00mm x 1.20mm x 2.00mm |
Piston Rings Included | Yes |
Second Ring Thickness | 1.2mm |
Piston Head Volume (cc) | -7.80cc |
Compression Height (in.) | 1.161 in. |
Top Ring Facing Material | Plasma-moly |
Manufacturer's Part Number | 930258401 |
Second Ring Facing Material | Cast iron |
Wrist Pin Retainers Included | Yes |
Accepts Aftermarket Rectangular Rod Or OE Tapered Small End. Voodoo Drop-In Forged Replacment Assembly No Balancing, No Comp Ratio Change. Performance Ring Set Included
Compatibility & Application Information | |
---|---|
Make | FORD |
Beginning Year | 2015 |
Ending Year | 2020 |
Engine Type | V8 |
Engine Family | Ford modular V8 |
Engine Size | 5.2L/315 |
