MAHLE Original pistons are OE quality and have the same great OE features such as compensated ring grooves to assure proper ring loading and oil control, as well as expansion controlled designs for small fitting clearances to reduce engine noise, wear, emissions, and improve oil control. MAHLE offers pistons ready for installation with mounted piston rings, with pin and clips included for the convenience of the engine builder.
Engine Piston Set
Mahle Original replacement pistons have the same great OE features to provide the perfect fit and function in your vehicle. They offer things like compensated ring grooves to ensure proper ring loading and oil control; as well as expansion-controlled designs for small fitting clearances—to reduce engine noise, wear, emissions, and improved oil control. Choose the model designed for your vehicle and engine application.
Brand | MAHLE Original |
Manufacturer's Part Number | 224-3729WR-0.50MM |
Part Type | Pistons |
Product Line | Mahle Original OE Replacement Pistons |
Summit Racing Part Number | MAH-2243729WR050 |
UPC | 27067006455 |
Piston Rings Included | Yes |
Bore (in.) | 3.799 in. |
Bore (mm) | 96.500mm |
Stroke | 3.622 in. |
Engine Stroke Type | Stock |
Piston Style | Flat top, with no valve reliefs |
Piston Material | Hypereutectic aluminum |
Compression Height (in.) | 1.329 in. |
Wrist Pin Style | Press-fit or floating |
Wrist Pin Retainers Included | Yes |
Wrist Pin Included | Yes |
Pin Diameter (in.) | 0.943 in. |
Piston Ring Thickness | 1.50mm x 1.50mm x 3.00mm |
File Fit | No |
Gapless | No |
Top Ring Thickness | 1.5mm |
Second Ring Thickness | 1.5mm |
Oil Ring Thickness | 3.0mm |
Remanufactured | No |
Quantity | Sold as a kit. |
Notes | Piston has a coated skirt. Designed for engines with 0.020 in. oversized bore. |
Mahle OE GM 4.8L / 5.3L 05-09 fits LMG LC9 LY5 & LMF .50MM Piston With Rings Set (Set of 8) | ||||
---|---|---|---|---|
Year | Make | Model | Submodel | Region |
2005 | GMC | Yukon | SLT | US |
2005 | Chevrolet | Tahoe | LS | US |
2005 | GMC | Savana 3500 | SLE | US |
2005 | Chevrolet | Express 2500 | Base | US |
2005 | Chevrolet | Express 2500 | LS | US |
2005 | Chevrolet | Express 3500 | Base | US |
2005 | Pontiac | Grand Prix | GXP | US |
2005 | Chevrolet | Silverado 1500 | WT | US |
2005 | Chevrolet | Trailblazer EXT | LT | US |
2005 | Chevrolet | Silverado 1500 | LS | US |
2005 | GMC | Sierra 1500 | WT | US |
2005 | Chevrolet | Silverado 1500 | LT | US |
2005 | GMC | Sierra 1500 | SLT | US |
2005 | Saab | 9-7x | Arc | US |
2005 | Buick | Rainier | CXL Plus | US |
2005 | GMC | Sierra 1500 | Base | US |
2005 | GMC | Envoy XUV | SLE | US |
2005 | GMC | Envoy | Denali | US |
2005 | GMC | Envoy XL | Denali | US |
2005 | GMC | Savana 2500 | SLE | US |
2005 | Buick | Rainier | CXL | US |
2005 | Chevrolet | Silverado 1500 | Base | US |
2005 | GMC | Sierra 1500 | SLE | US |
2005 | GMC | Savana 2500 | Base | US |
2005 | Isuzu | Ascender | S | US |
2005 | Isuzu | Ascender | Limited | US |
2005 | GMC | Envoy XL | SLE | US |
2005 | Isuzu | Ascender | LS | US |
2005 | GMC | Envoy XL | SLT | US |
2005 | GMC | Yukon | SLE | US |
2005 | GMC | Envoy XUV | SLT | US |
2005 | Chevrolet | Express 3500 | LS | US |
2005 | Chevrolet | Trailblazer EXT | LS | US |
2005 | GMC | Savana 3500 | Base | US |
2006 | GMC | Envoy | Denali | US |
2006 | Chevrolet | Express 2500 | Base | US |
2006 | Chevrolet | Express 2500 | LS | US |
2006 | Chevrolet | Express 2500 | LT | US |
2006 | Chevrolet | Trailblazer EXT | LS | US |
2006 | Saab | 9-7x | 5.3i | US |
2006 | Pontiac | Grand Prix | GXP | US |
2006 | Chevrolet | Silverado 1500 | WT | US |
2006 | Chevrolet | Silverado 1500 | LS | US |
2006 | GMC | Sierra 1500 | SL | US |
2006 | Chevrolet | Impala | SS | US |
2006 | GMC | Envoy XL | Denali | US |
2006 | Chevrolet | Trailblazer EXT | LT | US |
2006 | Chevrolet | Silverado 1500 | LT | US |
2006 | GMC | Sierra 1500 | WT | US |
2006 | Buick | Rainier | CXL | US |
Note: Over 50 fitments returned for this product, this table is trimmed to only display the first 50. |
